The 6308 motor bearing is a type of precision machinery component that is widely used in various types of motors. It plays a crucial role in ensuring the smooth and efficient operation of the motor. This bearing is specifically designed to withstand high loads and rotating speeds, making it s uitable for a wide range of applications. The 6308 motor bearing is manufactured from high-quality materials, ensuring durability and longevity even under harsh conditions. Its precision engineering ensure s smooth rotation and minimal friction, reducing wear and tear on the motor and extending its overall lifespan. Whether use d in industrial equipment, household appliances, or any other type of motor-driven device, the 6308 motor bearing is a reliable and efficient choice for maintaining optimal performance.
Bearing 6308 Specifications (English Version)
1. Bearing Type : Deep Groove Ball Bearing
2.Bearing Number: 6308
3.Dimensions:
·Bore Diameter (d):40mm.Outer Diameter (D): 90mm Width (B):23mm
4. Basic Load Ratings:
·Dynamic Basic Load Rating (Cr): 18 kN·Static Basic Load Rating (Cor): 10 kN
5. Limiting Speeds:
·Reference Speed (n1): 8000 r/min●Limiting Speed with Lubrication (Oil):9000 r/min
●Limiting Speed with Lubrication (Grease):7000 r/min
Material : Chrome Steel
Sealing Type: Open Type and seal
Precision Rating:PO(Standard Precision) p5 p6
Clearance Group : Normal Clearance (CN)
Application : Widely used in motors, automotive transmission systems,
machinery, household appliances,medical equipment, and other fields where bearings are required for rotational movement.
